Core Sensors CS84 Intrinsically Safe Differential Pressure Transducer

The CS84 intrinsically safe differential pressure transducer features an all-welded stainless steel construction for a minimum IP65 rating. A 316L SS oil-filled sensor element provides excellent stability over a wide operating temperature range, while offering corrosion resistance against various liquids and gases. The CS84 features differential pressure ranges up to 50 psi, optional bi-directional ranges, ¼-inch MNPT and FNPT process connections and a wide range of configurable options for operation in harsh conditions.

Core Sensors CS84 Intrinsically Safe Differential Pressure Transducer Applications
Filtration
External tank level measurement

Features

• Differential pressures up to 50 psi
• Bi-directional ranges available
• 500 psi max line pressure
• Accuracy:
  • ≤ ±0.25% BFSL
  • ≤ ±0.5% BFSL (2 psi and below)
• ≤ ±0.25% of full scale stability
• 4 million pressure cycles
• 2x or 500 psi (whichever is less) overpressure
• 3x rated differential pressure burst pressure
• Operating temperature:
  • -40 to 176°F (-40 to 80°C)
  • -4 to 176°F (-20 to 80°C) (electrical connection option F)
• Media temperature:
  • -40 to 257°F (-40 to 125°C)
  • -40 to 221°F (-40 to 105°C) (electrical connection option F)
• 32 to 131°F (0 to 55°C) compensated temperature
• TC Zero:
  • ≤ ±1% of full scale
  • ≤ ±2% of full scale (2 psi and below)
• TC Span:
  • ≤ ±1% of full scale
  • ≤ ±2% of full scale (2 PSI and below)
• EMI/RFI protection
• IP65 rating
